Overview
Parameters
- Fingerprint Capacity20,000
- Card Capacity10,000
- Transaction Capacity100,000
- CommunicationTCP/IP / RS485 (For Slave Reader) / Wiegand Input / Output / Security Relay Box
- Access Control InterfaceLock Relay Output / Lock Relay Output / Exit Button / Door Sensor / Doorbell Output
- Ingress Protection RatingIP65
- Hardware1.2GHz High Speed CPU / Memory 128MB RAM / 256MB Flash / Z-ID Fingerprint Sensor / 2.4 Inches TFT-LCD Screen / 125KHz EM Reader / IC Card (Optional) / Hi-Fi Voice & Indicator / Anti-dismantle Alarm / Touch Keypad
- Standard FunctionAccess Levels / Groups / Holidays / DST / Bell Schedule / Duress Mode / Anti-Passback / Record Query / Custom Wallpaper & Screen Saver
- Special FunctionMultiple Verification Modes / ZK Encrypted Card (Optional) / Fingerprint Card (Optional)
- CompatibilityWiegand Slave Reader / RS485 FP Slave Reader / ZKBioSecurity Software
- Operating Temperature-10°C ~ 50°C
- Dimension202.30 x 96.80 x 35.00mm
- AlgorithmZKFinger V10.0
- FingerprintFAR≤0.0001%, FRR≤0.01%
- Operating Voltage12V DC
- Current Draw< 500mA
